535W Aiko Neostar Dual-Glass Module Mono 3S+60 A535-MCE60Db All Black Solar Panel

The Aiko Neostar 535W Dual-Glass Mono Solar Panel (AIKO-A535-MCE60Db) is a premium high-efficiency solar module engineered with advanced N-Type ABC (All Back Contact) cell technology to deliver exceptional energy generation, durability, and long-term performance. Designed with a sleek all-black appearance, this panel is ideal for residential, commercial, and industrial solar installations where both aesthetics and efficiency matter.

Featuring a 535W power output and 24.1% module efficiency, the Aiko Neostar maximizes energy production while requiring less roof space compared to conventional solar panels. Its advanced cell architecture improves performance under partial shading conditions, offers enhanced temperature resistance, and delivers superior energy yields throughout the day.

The robust dual-glass construction with semi-tempered coated glass provides exceptional protection against moisture, environmental stress, micro-cracks, and mechanical loads, ensuring reliable operation even in demanding weather conditions. The module supports system voltages up to 1500V DC and is rated for front-side static loads up to 5400Pa, making it suitable for long-term outdoor installation.

Aiko backs the Neostar series with a 25-Year Product Warranty and a 30-Year Linear Performance Warranty, with first-year degradation limited to 1% and annual degradation from years 2 to 30 of only 0.35%, guaranteeing approximately 88.85% of original performance after 30 years.

Key Features

• 535W rated power output
• High-efficiency N-Type ABC cell technology
• 24.1% module efficiency
• Elegant all-black solar panel design
• Dual-glass construction for enhanced durability
• Excellent performance under partial shading conditions
• Low temperature coefficient of Pmax: -0.26%/°C
• Micro-crack resistance for extended module life
• IP68-rated junction box with MC4-EVO2A connectors
• Supports up to 1500V DC systems
• 25-Year Product Warranty
• 30-Year Linear Performance Warranty
• Low annual degradation for maximum lifetime energy production

Technical Specifications

• Model: AIKO-A535-MCE60Db
• Power Output: 535W
• Module Efficiency: 24.1%
• Cell Type: N-Type ABC Monocrystalline
• Number of Cells: 120 (6×20)
• Dimensions: 1954 × 1134 × 30 mm
• Weight: 27.1 kg
• Glass: Dual Glass (2.0 mm + 2.0 mm)
• Frame: Black Anodized Aluminum
• Maximum System Voltage: 1500V DC
• Operating Temperature: -40°C to +70°C
• Protection Class: Class II
• Junction Box Rating: IP68

Perfect for homeowners, businesses, solar installers, and EPC contractors seeking a high-performance, long-life solar panel with industry-leading efficiency, superior aesthetics, and outstanding energy yield.

Warranty

• 25-Year Product Warranty
• 30-Year Linear Performance Warranty
• Guaranteed long-term energy production and reliability

Applications

Perfect for:

• Residential rooftop solar systems
• Commercial solar installations
• Industrial energy projects
• High-efficiency solar arrays
• Premium all-black solar roof designs
• Areas with limited installation space

The 535W Aiko Neostar 3S+60 Dual-Glass All Black Solar Panel A535-MCE60Db offers one of the highest efficiencies available in today's solar market, delivering outstanding energy generation, long-term durability, and elegant aesthetics for customers seeking a premium solar solution.
