Sunsynk High Voltage Battery - 5.12kW Single Module, Battery Rack & BMU

Sunsynk High Voltage Battery – 5.12kW Single Module with Rack & BMU

Experience high-performance energy storage with the Sunsynk High Voltage Series, designed for scalable, efficient, and safe power solutions. This 5.12kW single module is part of a modular system that can be expanded up to 61.44kWh, making it ideal for residential, commercial, and industrial applications.

Key Features:

• Modular Design – Start with a 5.12kW module and scale up to 61.44kWh with 12 modules.
• High Voltage Efficiency – Operating voltage range: 538V to 691V.
• Fast Charge/Discharge – 1C rate with up to 100A current.
• Advanced Lithium Technology – Uses LiFePO₄ (Lithium Ferro-Phosphate) for safety and longevity.
• Long Lifespan – Backed by a 10-year warranty.
• Compact & Durable – IP20-rated enclosure with robust build quality.
• Smart Integration – Includes Battery Rack and BMU (Battery Management Unit) for seamless system control.

Technical Specifications:

• Energy Capacity: 5.12kWh per module
• Module Capacity: 100Ah
• Operating Voltage: 538V–691V
• Charge/Discharge Current: Max 100A
• Temperature Range: Charge: 0–55°C / Discharge: -20–55°C
• Dimensions (13-level rack): 589×590×2240mm
• Weight: 44–85kg per module / 628kg total (12 modules + rack)
• Altitude: ≤2000m
• Humidity: 5%–85% RH
• Certifications: EN/IEC 61000-6, IEC62619, UN38.3

Ideal For:

• Large-scale solar energy systems
• Commercial and industrial backup power
• High-voltage off-grid installations

Sunsynk High Voltage Battery Rack Specification Document

Sunsynk High Voltage Battery Rack User Manual
