Deye

Deye Battery HV 20.4kWh GB-L Set

Deye Battery HV 20.4kWh GB-L Set

Regular price R 89,635.00 ZAR
Regular price Sale price R 89,635.00 ZAR
Sale Sold out
Tax included.

Capacity

CONTACT US FOR RESELLER PRICING

The Deye GB-L 20.4kWh High Voltage Battery Set is a modular, floor-mounted energy storage solution engineered for high efficiency, safety, and intelligent control. Featuring advanced LiFePO4 (LFP) chemistry and a cable-free stacking design, this system is ideal for residential, commercial, and industrial energy applications.

Key Features:

  • High Voltage Stack Design: Modules connect in series without cables, improving system efficiency and simplifying installation.
  • Safe and Reliable: Built-in explosion relief and fire protection mechanisms ensure rapid response to thermal events.
  • Thermal Management: Real-time temperature monitoring of cells and connectors enhances safety and performance.
  • Wide Temperature Operation: Operates from -20°C to 60°C, with optional heating for cold environments.
  • Environmental Protection: IP65-rated enclosure and anti-corrosion grade ≥C2 for durability in harsh conditions.
  • Smart Monitoring: LCD display shows SOC, power, and voltage; supports remote upgrades and real-time alerts via CAN2.0 and RS485.

Technical Specifications:

  • Battery Type: LiFePO4 (LFP)
  • System Model: GB-L20
  • System Energy: 20.45kWh
  • Usable Energy: 18.4kWh (90% DOD)
  • Nominal Voltage: 512V
  • Operating Voltage Range: 166.4V – 700V
  • Charge/Discharge Current: Nominal 40A, Peak 50A
  • Cycle Life: ≥6000 cycles at 25°C, 0.5C/0.5C
  • Dimensions (W×D×H): 540 × 385 × 1310 mm
  • Weight: Approx. 214 kg
  • Installation: Floor-mounted
  • Certifications: CE, IEC62619, VDE2510-50, UN38.3
  • Warranty: Up to 10 years

Applications:

  • Solar energy storage systems
  • Backup power for homes and businesses
  • Off-grid and hybrid energy setups
  • Industrial energy management

Why Choose the Deye GB-L Series?

The Deye GB-L 20.4kWh battery set offers a future-proof, scalable solution for high-voltage energy storage. With intelligent features, robust safety mechanisms, and proven performance, it’s the ideal choice for demanding energy environments.


Deye Battery HV 20.4kWh GB-L Set Specifications Document
